Technical specification
DIMENSIONS
d 25 mm
D 37 mm
B 7 mm
D2 ≈ 34.2 mm
r1,2 min. 0.6 mm
ABUTMENT DIMENSIONS
da min. 27 mm
da max. 27.3 mm
Da max. 35 mm
ra max. 0.3 mm
CALCULATION DATA
Basic dynamic load rating C 4.36 kN
Basic static load rating C0 2.6 kN
Fatigue load limit Pu 0.125 kN
Limiting speed 11 000 r/min
Calculation factor kr 0.015
Calculation factor f0 14.2
MASS
Mass bearing 0.022 kg
